Introduction

Introducing world first 3D printable large format camera. Here the new revolutionary way of acquiring cameras meets with superb quality of 4×5 inch imaging area. It is about pure nature of photography, design and art. Please welcome “Entry 58”, compact 4×5 LF camera.

Ivancak Entry 58 detail1
Ivancak Entry 58 detail2

Features

Robust design optimized for 3D print from ABS filament. Imaging area almost 15 times bigger than 35mm full frame. Designed for Schneider Kreuznach Lenses either mounted on helical mount or mounted on the lens board as fix-focused to infinity. Standard available focal lengths are 58 and 90 mm. Compatible with all currently available sheet film holders as well as with Polaroid 545 instant film holder for New55 instant 4×5 film. Two cold shoes for accessories, 1/4” – 20 tripod thread and carrying strap attachments. Dimensions 158x137x65 mm (camera body). Customized focal length design on demand.

Important notice

1. How to get a camera?

We are opening completely new and exciting way of product delivery. You simply download the camera from our online store and the print it. Camera is designed in simple, minimalistic and foolproof design. Alternatively you can obtain “author’s print” from us. It is printed and adjusted camera body.

2. Whats in the box?

Download package includes:

  • .STL file with camera parts
  • Detailed instructions for 3D print
  • Recommended Slic3r setup parameters
  • Slic3r configuration files
  • Assembly instructions

Author’s print package includes:

  • 3D printed camera body and back springs
  • Adjusted lens position
  • Finishing in black color

3. What is Slic3r

Slic3r is an open source application, so called slicer, which prepares your model for 3D print. Other way – it translates you model into the language 3D printer understands.
LEARN MORE

4. What else do I need?

If you don’t have any equipment you will have to collect the gear. Please follow our equipment purchase guide here:

  • Schneider Super Angulon 58 XL lens
  • Schneider Helical Mount
  • Lightmeter
    • Buy at any suitable camera store

5. How do I print the camera?

If you are not familiar with 3D print, seek for 3D print service in your neighborhood, school
or online. Ask them to 3D print your camera according to instructions you will obtain from us.
We have prepared the instruction manual in a way that every professional skilled in 3D print will understand them.

6. How long is the printing time?

Using our setup parameters the printing time should take no longer then 15 hours 45
minutes (standard body). Fixed focus body requires a bit longer printing time.

7. Fix-Focused Bodies Depth of Field Chart

DoF_chart

• Near limit of acceptable sharpness in meters, lens focused do infinity
• Apply for fix-focused bodies respecting body focal length

1. How to get a camera?

We are opening completely new and exciting way of product delivery. You simply download the camera from our online store and the print it. Camera is designed in simple, minimalistic and foolproof design. Alternatively you can obtain “author’s print” from us. It is printed and adjusted camera body.

2. Whats in the box?

Download package includes:

  • .STL file with camera parts
  • Detailed instructions for 3D print
  • Recommended Slic3r setup parameters
  • Slic3r configuration files
  • Assembly instructions

Author’s print package includes:

  • 3D printed camera body and back springs
  • Adjusted lens position
  • Finishing in black color

3. What is Slic3r

Slic3r is an open source application, so called slicer, which prepares your model for 3D print. Other way – it translates you model into the language 3D printer understands.

LEARN MORE

4. What else do I need?

If you don’t have any equipment you will have to collect the gear. Please follow our equipment purchase guide here:

  • Schneider Super Angulon 58 XL lens
  • Schneider Helical Mount
  • Lightmeter
    • Buy at any suitable camera store

5. How do I print the camera?

If you are not familiar with 3D print, seek for 3D print service in your neighborhood, school
or online. Ask them to print your camera according to instructions you will obtain from us.
We have prepared the instruction manual in a way that every professional skilled in 3D print will understand them.

6. How long is the printing time?

Using our setup parameters the printing time should take no longer then 15 hours 45
minutes (standard body). Fixed focus body requires a bit longer printing time.

7. Fix-Focused Bodies Depth of Field Chart

DoF_chart

• Near limit of acceptable sharpness in meters, lens focused do infinity
• Apply for fix-focused bodies respecting body focal length

Gallery

Take your choice

Download source file – 49 $

  • .STL files with camera model
  • Instructions for 3D print
  • Slic3r parameter setup file (.ini bundle)
  • Assembly instructions
  • Price: 49 $
    • Price includes 21% VAT (Czech Republic)

Options:

  • Standard body 58 mm
    • Enables precise focusing
    • Requires Schneider helical mount
  • Fix-focused body 58 mm
    • No helical mount needed
    • Focused to infinity i.e. 3 – ∞ meters
  • Standard body 90 mm
    • Enables precise focusing
    • Requires Schneider helical mount
  • Fix-focused body 90 mm
    • No helical mount needed
    • Focused to infinity i.e. 3 – ∞ meters
source file

Order “Author’s print” – 174 $

  • Completed 3D printed camera body (without additional equipment!)
  • Precisely adjusted for 58 mm or 90 mm lens (depends on type of order)
  • Finished in black coating
  • Price: 174 $. Price includes:
    • Free shipping
    • 21% VAT (Czech Republic)

Options:

  • Standard body 58 mm
    • Enables precise focusing
    • Requires Schneider helical mount
  • Fix-focused body 58 mm
    • No helical mount needed
    • Focused to infinity i.e. 3 – ∞ meters
  • Standard body 90 mm
    • Enables precise focusing
    • Requires Schneider helical mount
  • Fix-focused body 90 mm
    • No helical mount needed
    • Focused to infinity i.e. 3 – ∞ meters
Ivancak Entry 58 front left

Require custom design

STL file rendering – 159 $

  • .STL file with customized focal length according to customer needs
  • Standard bodies available focal lengths: 72 mm, 100 mm, 120 mm, 150 mms
  • Fix focused bodies available focal lengths: any large format Schneider Kreuznach lens with focal length up to 180 mm
  • We will contact you after an order and finish the details
  • Price: 159 $. Price includes:
    • 21% VAT (Czech Republic)

Customized „Author’s print“ – 429 $

  • Completed 3D printed camera body (without additional equipment!)
  • Standard bodies available focal lengths: 72 mm, 100 mm, 120 mm, 150 mms
  • Fix focused bodies available focal lengths: any large format Schneider Kreuznach lens with focal length up to 180 mm
  • We will contact you after an order and finish the details
  • Price: 429 $. Price includes:
    • Free shipping
    • 21% VAT (Czech Republic)

Buy Schneider helical mount – 349 $

  • Compulsory accessory for standard camera body
  • Allows focusing from 0,4 meters to infinity
  • Manufactured by Schneider-Kreuznach exclusively for Schneider Super Angulon 58/90 XL lens
  • Price: 349 $. Price includes:
    • Free shipping
    • 21% VAT (Czech Republic)

Options:

  • For Super Angulon 58 mm XL
  • For Super Angulon 90 mm XL
Schneider- Kreuznach Helical Mount

Buy Fotoman’s accessories (only in European Union)

Fotoman Auxiliary Rangefinder

Fotoman Range Finder
  • provides precise distance to the intended subject
  • high quality optics and the latest optical coatings
  • single piece of high quality aluminum
  • Price: 364$. Price includes:
    • Free shipping (only to EU!)
    • 21% VAT (Czech Republic)

Fotoman Optical Viewfinder 4×5

Fotoman View Finder
  • 120 degree Viewfinder
  • features an integral top mounted circular bubble level
  • for 4×5 film format
  • Price: 319$. Price includes:
    • Free shipping (only to EU!)
    • 21% VAT (Czech Republic)

Fotoman Optical Viewfinder Mask

Fotoman View Finder Masks
  • precise interchangeable Masks for Fotoman’s Viewfinder
  • more accurate framing and composition
  • available for 4×5 58mm or 4×5 90mm
  • Price: 124$. Price includes:
    • Free shipping (only to EU!)
    • 21% VAT (Czech Republic)

Options:

  • Format 4×5 58 mm
  • Format 4×5 90 mm
